Architectural Geometric Etched Stainless Steel Sheet Decorative Metal Panels

Exquisite Geometric Artistry

Crafted from premium stainless steel, this etched geometric panel showcases a sophisticated interplay of patterns inspired by architectural and natural forms. Each intricate design is precision-etched to create a striking visual texture, offering both durability and artistic elegance. Ideal for adding a modern yet timeless accent to any space.

Versatile and Functional Design

This decorative metal sheet is not only visually captivating but also highly practical. Resistant to corrosion, scratches, and wear, it is perfect for both indoor and outdoor applications. Use it as a backsplash, room divider, wall art, or even furniture embellishment. Its easy-to-clean surface ensures lasting beauty with minimal maintenance.

Elevate Your Décor Effortlessly

Transform your home, office, or commercial setting with this versatile panel. The reflective quality of stainless steel enhances light and depth, making spaces feel larger and more dynamic. Whether used as a focal point or a subtle complement, it seamlessly blends with various styles—from industrial and minimalist to rustic and contemporary.

The production of colored stainless steel sheets via PVD (Physical Vapor Deposition) involves three core stages: pre-treatment, PVD coating deposition, and post-treatment, with strict parameter control throughout.

This stage ensures a clean, smooth surface for coating adhesion.

Cutting & Polishing: Cut stainless steel coils/plates to required dimensions via laser or shearing. Polish with abrasive belts/wheels to achieve finishes like mirror, brushed, or matte, and remove minor scratches.

Cleaning: First, degrease with alkaline/solvent solutions to eliminate oil and fingerprints. Then, pickle with nitric-hydrofluoric acid to remove oxide layers and polishing residues. Finally, rinse with deionized water and dry with hot air/infrared to avoid water spots.

Completed in a high-vacuum chamber to ensure coating quality.

Vacuum Setup: Load dried substrates into the chamber, then pump to 10⁻³–10⁻⁵ Pa (high vacuum). Heat substrates to 150–300°C and use argon ion bombardment for deep cleaning.

Target Sputtering & Reaction: Select targets based on color (e.g., titanium for gold, chromium for silver). Use magnetron sputtering (plasma bombards targets to release atoms) or arc ion plating (electric arc melts targets) to vaporize targets. Introduce reactive gases (nitrogen for nitrides, oxygen for oxides); target atoms react with gases to form colored compound films (e.g., TiN for rose gold) on substrates.

Thickness Control: Monitor via a quartz crystal sensor to keep coating thickness at 0.1–1 μm (too thin = poor fastness; too thick = brittleness).

This stage enhances performance and ensures compliance.

Cooling & Finishing: Cool the chamber to room temperature, release vacuum, and unload. Optionally, lightly polish coated surfaces for better gloss.

Quality Checks: Test coating hardness (≥2000 HV via Vickers tester) and adhesion (no peeling via cross-cut tester). Use a spectrophotometer to verify color consistency (ΔE ≤ 1 vs. standards).

Packaging: Wrap qualified sheets in anti-scratch film, then pack in cartons/wooden pallets for transport.

Crafted from premium-grade stainless steel, our Etched Geometric Pattern Panel combines durability with refined elegance, making it ideal for both interior and exterior architectural applications. Resistant to corrosion, weathering, and daily wear, this decorative metal sheet maintains its luster and structural integrity over time, even in high-traffic or harsh environments. The precision-etched geometric motifs offer a modern, artistic touch that elevates any space—from corporate lobbies to luxury residences—while ensuring long-term performance without fading or chipping.

Each panel is laser-etched with meticulous attention to detail, delivering crisp, consistent patterns that reflect sophistication and contemporary design sensibility. Available in customizable sizes and finishes—including brushed, mirror, or matte—the panels adapt seamlessly to diverse aesthetic visions. Whether used as wall cladding, room dividers, elevator interiors, or façade accents, the interplay of light and shadow across the etched surfaces creates dynamic visual interest that evolves throughout the day, transforming static architecture into living art.

Beyond beauty, these panels offer practical advantages: lightweight yet rigid, easy to install with standard mounting systems, and requiring minimal maintenance—simply wipe clean to restore brilliance. Their modular nature allows for creative configurations, enabling designers to scale installations from intimate feature walls to expansive architectural statements. Environmentally conscious and 100% recyclable, our stainless steel panels represent a sustainable choice without compromising on style or strength, making them the intelligent selection for forward-thinking architects and discerning property owners alike.
