Silicon Steel Coil Amorphous Magnetic Core with High Saturation Magnetic Induction Low Magnetic Loss and Good Frequency Performance

Silicon Steel Coil Amorphous Magnetic Core with High Saturation Magnetic Induction Low Magnetic Loss and Good Frequency Performance
Silicon Steel Coil Product Performance High saturation magnetic induction Bs Low magnetic loss compared to other materials Excellent frequency and temperature performance, suitable for 3000KHz applications High DC bias characteristics Low magnetic leakage rate Lighter weight and smaller size ...
Place of Origin:Guangdong, China
Certification:ISO9001&ISO14001
Price:Negotiable
Product Custom Attributes
Highlight

High Saturation Magnetic Induction Silicon Steel Coil

,

Low Magnetic Loss Amorphous Magnetic Core

,

Good Frequency Performance Magnetic Core

Product Description
Silicon Steel Coil
Product Performance
  • High saturation magnetic induction Bs
  • Low magnetic loss compared to other materials
  • Excellent frequency and temperature performance, suitable for 3000KHz applications
  • High DC bias characteristics
  • Low magnetic leakage rate
  • Lighter weight and smaller size compared to alternative materials
Technical Specifications
Density 7.3 g/cm³
Curie temperature Tc = 410°C
Essence temperature Tx = 530°C
Saturation Bs = 1.56T
Resistivity ρ = 130 Ω-cm
Saturated magnetic stretching performance λs = 27*10⁻⁶
Product Description
We provide amorphous magnetic cores for automotive audio systems and perform wire winding processing. Standard magnetic core specifications are available.
Customization Options
Magnetic cores can be customized according to customer specification drawings. Required parameters for customization include:
  • Core size and shell dimensions
  • Parameter performance AL @ DC bias = 0A and other AL values under different DC currents
  • Copper wire diameter specifications
Primary Applications
  • SMS output choke
  • DC/DC conversion choke coil
  • Ordinary mode choke
  • Choke for adapters and battery chargers
  • PFC choke
  • Car audio systems
